Robust Power Output, Superior Audio Quality, and Efficient Operation

Yamaha's audio engineers have specifically designed the new P-Series power amplifiers to be perfect companions to the popular Club Series loudspeakers. To achieve this, they made sure that the amplifiers are capable of delivering power that matches the power handling capabilities of the Club Series Speakers, and equipped them with YS Processing (Yamaha Speaker Processing) to deliver a signal that will result in optimum system performance.
Power is plentiful, ranging from 3200 watts from the P7000S to 1300 watts from the P2500S in 4 ohms bridged mode. If you want the perfect power amplifier for pair of Club S115s with a 500-watt program rating, for example, the P5000S with 500-watts per channel into 8 ohms is the obvious choice.
Further matching precision is afforded by Yamaha's proprietary YS Processing circuit. Each P-series amplifier is equipped with this specially designed circuit so that it delivers output tailored to the specific response of the Club Series speakers. All models feature both XLR and 1/4-inch TRS inputs, and Neutrik speakON, phone plug, and 5-way binding post outputs. Other features include Yamaha's exclusive EEEngine technology for high performance with exceptional efficiency, sweepable high and low pass filters for matching output to any loudspeakers, a compact and durable 2U chassis, and variable speed cooling fans.



Big Power with Outstanding Efficiency

The new P-Series Power Amplifiers deliver solid, professional-quality power in a wide range of configurations designed to suit a variety of applications. In 4 ohmas bridged mode the P7000S delivers 3200 watts, the P5000S 2600 watts, the P3500S 2000 watts, and the P2500S 1300 watts.
Those on a budget will find the lineup's high power output and affordable prices offer superior quality without putting a strain on allotted funds. Further savings are realized with extremely efficient operation utilizing Yamaha's exclusive EEEngine technology, which keeps operational costs down by significantly reducing AC power consumption and heat generation.

The Perfect Match for Your Club Speakers

The new P-Series Power Amplifiers can be used with any loudspeaker system, but if you're using our Club Series speakers they will provide optimum power and performance. In an 8Ω stereo application, power output per P7000S channel is 700 watts (650 watts on the 230V model), the P5000S puts out 500 watts per channel, the P3500S delivers 350 watts per channel, and the P2500S outputs 250 watts per channel. This wide selection lets you choose the amplifier that best matches the power handling capabilities of your speaker system.
All four models are equipped with independent sweepable high-pass and low-pass filters on each channel so you can optimize output for subwoofer or full range systems.

Light Weight for Easy Transport and Setup

Look at the specifications and you'll notice that the P2500S and P3500S are surprisingly light in weight, making transport and setup less of a chore. What is really impressive, however, is the difference in weight per watt when you look at the P5000S and P7000S. The use of an advanced switching power supply makes these two models very lightweight while maintaining superior audio quality.

Versatile Connectivity

To provide the most versatile connectivity possible, all four models are equipped with Neutrik speakON* output jacks and 1/4-inch output jacks for each channel, in addition to 5-way binding post. Balanced XLR and 1/4-inch TRS jacks are provided for channel input





General specifications

Model		P7000S	P5000S	P3500S	P2500S
Dynamic power; 1kHz; 20ms nonclip	2ohms; Stereo	1600Wx2	1300Wx2	1000Wx2	650Wx2
	4ohms; Bridge	3200W	2600W	2000W	1300W
Output power; 1kHz	4ohms; Stereo	1100Wx2	750Wx2	590Wx2	390Wx2
	8ohms; Stereo *:230V model	750Wx2 650Wx2*	525Wx2	390Wx2	275Wx2
	8ohms; Bridge	2200W	1500W	1180W	780W
Output power; 20Hz-20kHz	4ohms; Stereo	950Wx2	700Wx2	450Wx2	310Wx2
	8ohms; Stereo	700Wx2	500Wx2	350Wx2	250Wx2
	8ohms; Bridge	1900W	1400W	900W	620W
		P7000S	P5000S	P3500S	P2500S
Power bandwidth		10Hz-40kHz
Total harmonic distortion		Less than 0.1% (20Hz-20kHz; Halfpower)
Inter moduration distortion		Less than 0.1% (60Hz:7kHz=4:1, Half Power)
Frequency response		0, +0.5, -1dB; 20Hz-50kHz
S/N ratio		More than 104dB	More than 103dB	More than 102dB	More than 100dB
Residual output noise (DIN AUDIO)		Less than -70dBu
Crosstalk		Less than -70dB
Damping factor		More than 350		More than 200
Maximum input level		+22dBu
Maximum voltage gain		32.1dB
Input sensitivity @8ohms		+7.4dB	+6.5dB	+5.2dB	+3.6dB
Processors		HPF/LPF (25Hz-150 sweepable, 12dB/Oct), YS Processing
I/O connectors	Line input / output ports	XLR3-31 type /ch(balance) TRS Phone /ch(unbalance)
	Speaker output ports	speakON /ch 5-way binding post /ch Phone jack /ch(unbalance)
Protection circuit	Load protection	POWER switch ON/OFF mute; DC-fault (power supply shutdown)		POWER switch ON/OFF mute; DC detection
	Amplifier protection	Temp. detection (Heat sink temp ≥90°C), VI limiter (RL≤1ohm)
Amplifier class		EEEngine
Cooling		Dual variable-speed fan		Single variable-speed fan
Power requirements		AC120V, 230V or 240V 50/60Hz
Power consumption	Music source equivalent	650W	500W	450W	320W
	Idling	35W	35W	30W	25W
Dimensions	Width	480mm; 18-7/8"
	Height	88mm; 3-7/16"
	Depth	456mm; 17-15/16"
Net weight		12kg; 26.5lbs	12kg; 26.5lbs	15kg; 33.1lbs	14kg; 30.9lbs
