The TS2.10 is the mid-level active subwoofer in Tannoy’s innovative and powerful TS2 range. These compact domestic subwoofers draw on Tannoy’s extensive professional and stadium loudspeaker design experience to deliver class-leading low frequency drama and thunderous bass effects. Designed to excel in speed and power, each model uses a powerful digital amplifier and two large, long-throw drivers to output extremely fast and deep bass. The design allows considerable LFE output from a compact cabinet, making the TS2 range ideal for a wide range of home cinema systems.
Inside the double-thickness cabinet the TS2.10 uses the latest class-D digital amplifier technology, running in highly efficient bridge mode and delivering a prodigious 300 Watts RMS of deep bass power. Replacing traditional analogue filter networks, the TS2’s high-speed Digital Signal Processing (DSP) engine handles bass management and all user adjustments. These include simple rotary controls for roll-off frequency, phase and gain, making the TS2 subwoofers as simple to set-up and as they are potent to use. An auto power on/off feature eliminates the need to access the TS2’s controls once set up and further ensures the most power-efficient operation.
Specifications
Performance |
Output power
|
300 W RMS |
Low frequency response (-6 dB) |
24 Hz |
Inputs |
2 x phono line level, LFE or stereo |
Outputs |
2 x phono line level, LFE or stereo |
Input filter |
50 - 150 Hz, 2nd order low pass, with bypass provision |
Driver type |
10" (250 mm) active & passive ABR |
Enclosure type |
Closed box, side firing |
Enclosure volume |
23.1 litre (0.82 cu. ft.) |
Additional features |
Variable phase control 0 - 180 degrees
Signal sensing or always on operation |
Dimensions H x W x D
|
390 x 380 x 328 mm (15.4 x 15 x 13") |
Enclosure weight |
14.5 kg (31.9 lbs) |
Finishes |
Dark grey vinyl |
|
|
