YAMAHA RX-V771
3D-Ready AV Receiver / USB / Network / 7.1 Channel Digital Home Theater
$ .-
Audio Features
• 7-channel powerful surround sound, 665W = 95W x 7 (8 ohms, 20 Hz-20 kHz, 0.09 % THD, 2 ch driven); 1,120W = 160W x 7 (8 ohms, 1 kHz, 10 % THD, 1 ch driven, JEITA)
• HD Audio format decoding: Dolby TrueHD and DTS-HD Master Audio; Dolby Digital Plus and DTS-HD High Resolution Audio
• Discrete amp configuration
• Pure Direct for highest resolution sound
• Low jitter PLL circuitry helps optimize sound imaging
• Assignable amplifiers for bi-amp connection
• Intelligent assignable amplifiers for Surround Back to Front Presence or Zone 2
Video Features
• Analog and HDMI video upscaling to full HD 1080p
• 1080p-compatible HDMI: 6 inputs (1 on front) and 2 output (simultaneous)
• Supports Deep Color (30/36 bit), x.v.Color, 24Hz Refresh Rate and Auto Lip-Sync compensation
• High quality video processing with precise deinterlacing
- Motion adaptive and edge adaptive deinterlacing
- Multi-cadence (incl. 3-2 pull-down) detection
• HDMI with 3D and Audio Return Channel
Advanced Features
• SCENE buttons (BD/DVD, TV, CD and Radio)
- Quick and simple to use
- HDMI CEC powers up compatible TVs and Blu-ray Disc™ players
• Network functions
- AV Controller app for operating various functions from an iPhone, etc.
- Access to: Internet Radio (vTuner): MP3, WMA
Music files on PC: WAV, MP3, WMA, AAC, FLAC
- DLNA 1.5 certified
• Front panel USB Digital Connection for iPod and iPhone
• Advanced multi-language GUI on-screen display with album art
• HDMI front panel input for devices such as camcorders and digital cameras
• HDMI CEC with versatile control from AV Receiver remote control
• YPAO sound optimization with multi-point measurement
• Audio input assign capability for HDMI and component video input
• Ability to change HDMI Input while in Standby Through mode
• iPod/iPhone compatibility with optional YDS-12 Universal Dock
• Wireless connection for iPod/iPhone with optional YID-W10
• Bluetooth (A2DP) compatibility with optional Yamaha Bluetooth® Wireless Audio Receiver YBA-10
• iPod/iPhone song titles displayed in English and Western European languages on the front panel and on-screen display
• Dialogue Lift
• Audio Delay for adjusting Lip-Sync (0-250ms)
• Preset remote unit
• Background video feature (for tuner and USB only)
Surround Realism
• HD Audio decoding with CINEMA DSP 3D (17 DSP programs)
• Compressed Music Enhancer with CINEMA DSP
• Virtual Presence Speaker function for CINEMA DSP 3D surround without Front Presence Speakers
• Adaptive DRC (Dynamic Range Control) and Adaptive DSP Level
• SILENT CINEMA and Virtual CINEMA DSP
Versatile Zone Control
• Zone 2 on/off and control on front panel
• Zone sleep and system sleep
• Party mode
• Remote input/output
• Programmable +12V trigger output
Eco-Friendly Design
• Auto power down function with variable time setting
• Low Standby Power Consumption of 0.1W
• Low Standby Power Consumption of 2.0W (HDMI Standby Through mode)
Especificaciones
| Amplifier Section | Channel | 7.2 |
|---|---|---|
| Rated Output Power (1kHz, 1ch driven) | 130W (8ohms, 0.9% THD) | |
| Rated Output Power (20Hz-20kHz, 2ch driven) | 95W (8ohms, 0.09% THD) | |
| Maximum Effective Output Power (1kHz, 1ch driven) (JEITA) | 160W (8ohms, 10% THD) | |
| Dynamic Power per Channel (8/6/4/2 ohms) | 140/180/210/250W | |
| Surround Sound Processing | CINEMA DSP | Yes (3D) |
| DSP Programs | 17 | |
| Compressed Music Enhancer | Yes | |
| Virtual Presence Speaker | Yes | |
| Dialogue Lift | Yes | |
| SILENT CINEMA / Virtual CINEMA DSP | Yes | |
| Dolby TrueHD | Yes | |
| Dolby Digital Plus | Yes | |
| Dolby Pro Logic IIx | Yes | |
| DTS-HD Master Audio | Yes | |
| Audio Features | Pure Direct | Yes (with video on mode) |
| YPAO sound optimization | Yes | |
| YPAO multi-point measurement | Yes | |
| Adaptive DRC (Dynamic Range Control) | Yes | |
| Initial Volume & Maximum Volume Setting | Yes | |
| Bi-amp capability | Yes | |
| Audio Delay | Yes (0-250 ms) | |
| 192kHz/24-bit DACs for all channels | Yes (Burr-Brown) | |
| Video Features | HDMI 3D passthrough | Yes |
| HDMI Audio Return Channel | Yes | |
| Component upconversion | Yes | |
| HDMI upscaling | Yes (Analog to HDMI / HDMI to HDMI) | |
| Deep Color/x.v.Color/24Hz Refresh Rate /Auto Lip-Sync | Yes | |
| Connectivity | HDMI Input/Output | 6 (front 1) / 2 (Simultaneous) |
| HDMI CEC | Yes (SCENE, Device Control) | |
| USB Input | iPod/iPhone, USB Memory, Portable Audio Player | |
| Network Port | vTuner Internet Radio | |
| Dock Port | 1 (YDS-12, YID-W10, YBA-10) | |
| Front AV Input | HDMI/USB/Analog Audio/Composite | |
| Digital Audio Input/Output: Optical | 2 / 0 | |
| Digital Audio Input/Output: Coaxial | 2 / 0 | |
| Analog Audio Input/Output | 6 (front 1) / 1 | |
| Phono Input | Yes | |
| Component Video Input/Output | 2 / 1 | |
| Composite Video Input/Output | 5 (front 1) / 1 | |
| Preout | 7.2ch | |
| Headphone Output | 1 | |
| Tuner Section | FM/AM Tuner | Yes |
| User Interface | On-screen display | Graphical User Interface |
| SCENE | SCENE (4 sets) | |
| App Control | Yes | |
| Web Browser Control | Yes | |
| Remote Control Unit | Yes (Preset) | |
| Zone Control | Zone 2 Audio Output | Line output |
| Powered Zone | Zone 2 | |
| +12V Trigger Output | 1 | |
| Remote (IR) Input/Output | 1 / 1 | |
| Party Mode | Yes | |
| General | Standby Power Consumption (IR only) | ≤0.1W |
| Auto Power Down | Yes | |
| Dimensions (W x H x D) | 435 x 171 x 368 mm | |
| Weight | 11.2 kg |
