YAMAHA R-S201

Natural Sound Stereo Receiver




YAMAHA R-S201







YAMAHA R-S201



$ 10400.-



  • Yamaha high sound quality, created by rich experience and tradition and high technological expertise
  • 40 station FM/AM preset tuning
  • Simple and sophisticated design
  • Speaker selector and speaker terminals for two systems
  • Simple design remote control
  • Headphone terminal



Yamaha High Sound Quality, Created by Rich Experience and Tradition and High Technological Expertise

The R-S201 was created by taking advantage of this rich experience and high technological expertise. Based on the concept of “Natural Sound” for reproducing all music as it really sounds and built with scrupulous care - from circuit design to basic sound production. Even though it is an entry model, it reproduces high sound quality and musically rich sound.



100 W x 2 High Output Power* and High Sound Quality Circuit Design

The R-S201, with 100 W* x 2 high drive power that's above its class, has a high sound quality design that minimizes the length of signal routes and optimizes the circuit layout. Positioning the power transformer near the power amp circuit reduces power loss while improving peak power supply capacity to enable high volume output. The signal ground and power supply ground are connected at one point, eliminating mutual interference to achieve a higher S/N ratio. The result is sound filled with clarity and a feeling of openness.

*8 ohms, 40 Hz - 20 kHz, 0.2% THD



Speaker Selector and Speaker Terminals for Two Systems

Equipped with speaker terminals for two systems, this receiver lets you can connect two sets of speakers. The speaker selector makes it easy to switch between speaker outputs, allowing you to hear the sound from one speaker system (A or B) or from both (A+B).



Power Saving

A power management function automatically cuts off the power (switches to standby mode) when the receiver has not been operated for a long time. It can be set to two, four, eight or 12 hours, or off. In addition, power consumption during standby is only 0.5 W, achieving good energy saving performance.



YAMAHA R-S201
